Model:
|
APOLLO 20, APOLLO 30, APOLLO 40, APOLLO 50
|
Max. Cylinder Length(mm):
|
1100, 1500, 2400, 3700
|
Cylinder Girth(mm):
|
250-1800
|
Rotate Speed (rpm):
|
10-600
|
Engraving Speed (dots/s) :
|
≤4500
|
Range of Screen (l/cm):
|
40-140
|
Repeat Precision (mm):
|
≤0.03
|
Cell Depth (mm):
|
0-0.07
|
Range of Channel (mm):
|
0-0.25
|
Range of Cell (mm):
|
0-0.25
|
Engraving Methods:
|
continuous & step
|
Cell Angle:
|
5 kinds of angle, free choice
|
Environment Temperature:
|
18 ~25; Humidity:℃℃ 40%~70%(at 20°C)
|
Total net machine weight(kg):
|
2300
|
Overall machine dimension (mm):
|
3300*960*1540
|
Aptitudinal Skipping:
Many rollersusually require Engravingmerely ina fewlocations andno Engravingsinotherareas else. For these rollertheuser merely are required topreset relatedparameters inComposing Work Stationand during theEngravingthe Engraving Systemwillautomatically make fast feed andpositioning, which greatly improves the Engravingefficiency.
SeveralDataInput Modes:
In accordance with international unifiedsoftware interface standard, the system can receive common pre-printingsystemdata,such asdata from Apple-Macintosh, PC, and Full Pagemakeupsystem and data may be in-linereceivedoroff-line received throughcommon-marketed datacarrier
Best Economical Benefits:
Digital Engraving inTIFF-formateddata shortens thetimefrom forming design ideato completing the roller Engraving.All the adopted new technologiessuch as full-servocontrol system andhigh-speed Engraving Head effectively enhance the Engraving speed and precision and the system reliability, and the good man-machine interface improves operation speed and efficiency and renders considerable economical benefits.
