the coating width: | 1100mm |
the roller surface width: | 1230mm |
Max Film Width: | 550mm |
mechanical speed: | 130m / min (production speed with the coating thickness about) |
unwinding diameter: | Φ1100mm |
winding diameter: | Φ800mm |
Heating: | Electric heating |
the temperature control: | room temperature -150 ℃ ± 2 ℃ |
winding edge uniformity: | ± 0.5mm |
installed power: | about 180kw |
the device dimensions: | 26500mm × 3400mm × 4200mm |
