Station for 4-color flexo printing machine:
　　1.One mounting machine
　　2.One anilox roller for each group (lpi is optional, made in shanghai)
　　3.Three sets printing rollers (3*4=12)
　　4.Printing both sides at the same time (with turn bar)
　　5.With the lamination station
　　6.One unwinding tension controller (Mitsubishi Japan)
　　7.One rewinding tension controller
　　8.One rotary die cutting station

Main technical parameter:

Model：	RY480-4B
Speed：	60m/min
Printing color：	4colors
Max. Web width：	480mm
Max. Printing width：	460mm
Max. Unwinding diameter：	800mm
Max. Rewinding diameter：	750mm
Printing girth：	175-580mm
Precision of registration：	±0.10mm
Dimensions：	2100*1300*2500(mm)
Machine weight：	About 2600kg
